Industrial lamp fixture ATEX E27 IP66

Reference BDD81E27EX

€174.45

VINAC 220-240V

Más datos técnicos+ Info

Cap type

E27 cap En Stock

Quantity

Safe purchase through secured payment gateway
24/48h shipping mainland Spain
Return period 15 days
Up to 5-year warranty

Product Details
Manuals and downloads

Reference BDD81E27EX

Data sheet

SizeØ146 x 250 mm
VINAC 220-240V
Frequency (HZ)50/60 hz
Materialaluminum
ConnectorE27
IP gradeIP66
Working temperature-40ºC / +55ºC
Certifications
Weight2.80 Kg.
Warranty5 years

Download

download Manual de instrucciones

Manual en español - (399.14k)

download Datasheet in English

- (386.24k)

download Manual BDD81E27EX

- (219.09k)

Description

Industrial lamp made of aluminium and reinforced glass, for surface mounting, with ceramic lamp holder for E27 threaded bulbs.

It has protection against atmospheres susceptible to cause explosions, certified under the strict IECEx directive.

Its IP66 degree of protection allows it to be installed in wet areas.

The lower part consists of a round junction box with four metric M25 x 1.5 threaded conduits (closed with a hexagonal plug). ATEX M25 cable glands must be purchased for the tracks to be used.

Ideal luminaire for factories, warehouses, workshops, industrial warehouses, ships, paint booths, petrol stations and areas with potentially explosive atmospheres in general.

Characteristics:

- Aluminium housing and tempered glass shade, with stainless steel grille.

- Painted by electrostatic spraying, with a high degree of corrosion resistance.

- Suitable for zones 1 and 2 (gases) + 21 and 22 (dust).

- Marking II 2 G Ex d IIC T4 Gb

II 2 D Ex t IIIC T130°C Db IP66

- Maximum bulb size allowed: Ø70mm x 120 mm.

- Hermetically sealed by thread (fixed with hexagonal head captive screw H2).

Compatible only with E27 socket bulbs.

(Bulb not included)
