ATEX LED Flood light 50W Emergency Function Mean Well

The ATEX LED 50W Flood light is designed for installation in industrial environments with explosion risk due to flammable gases or combustible dust. This model complies with the ATEX Directive 2014/34/EU, ensuring safe operation in zones classified 1, 2, 21, and 22.

Designed to illuminate ATEX spaces requiring emergency lighting, this floodlight features high-performance Lumileds 3030 LED technology, providing powerful, stable, and efficient illumination even in demanding industrial environments.

Emergency function and backup battery

This floodlight includes an internal backup battery that allows the luminaire to remain lit at 10% of its total power (approximately 550 lumens) for up to 90 minutes in case of power failure, ensuring safety and visibility in critical situations.

Luminosity performance and industrial reliability

With a nominal power of 50W, this floodlight provides a luminous flux of up to 5,500 lumens in normal mode, with a lifespan of up to 50,000 hours. The illumination is stable, efficient, and reliable, reducing maintenance and replacement costs.

Designed for extreme conditions

The floodlight has an IP66 protection rating and IK10 impact resistance, making it suitable for indoor and outdoor use under extreme conditions, including humid environments and maritime applications. Its housing is made of aluminum with WF2 anti-corrosion treatment, ensuring maximum durability and resistance in harsh environments.

Installation and technical considerations

Includes an adjustable bracket, allowing installation on walls, ceilings, or poles according to project requirements. The power cable is not included and must be compatible with ATEX installations, with a minimum diameter of 7 mm, compatible with the luminaire's cable gland.

Recommended spaces

The ATEX LED 50W floodlight with emergency function is ideal for:

• Industrial plants requiring emergency lighting
• ATEX zones with explosion risk
• Areas requiring safety lighting during power outages

Recommended installation height: 4 to 6 meters.

Frequently Asked Questions

How long does the emergency battery last?

The battery is designed to operate for a maximum of 90 minutes in emergency mode, complying with international safety and evacuation standards in industrial environments.

What is the emergency function of the ATEX LED 50W floodlight?

The emergency function allows the floodlight to remain on during a power outage. If the mains supply fails, the internal battery automatically activates, providing illumination at 10% of total power (approximately 550 lumens) for up to 90 minutes.
